Rate this post Packet Tracer – Configure Cisco Routers for Syslog, NTP, and SSH Operations TopologyAddressing TableObjectives. Configure OSPF MD5 authentication.
Configure NTP. Configure routers to log messages to the syslog server. Configure R3 to support SSH connections. Background / ScenarioIn this activity, you will configure OSPF MD5 authentication for secure routing updates.The NTP Server is the master NTP server in this activity. You will configure authentication on the NTP server and the routers.
You will configure the routers to allow the software clock to be synchronized by NTP to the time server. Also, you will configure the routers to periodically update the hardware clock with the time learned from NTP.The Syslog Server will provide message logging in this activity. You will configure the routers to identify the remote host (Syslog server) that will receive logging messages.You will need to configure timestamp service for logging on the routers. Displaying the correct time and date in Syslog messages is vital when using Syslog to monitor a network.You will configure R3 to be managed securely using SSH instead of Telnet. The servers have been pre-configured for NTP and Syslog services respectively. NTP will not require authentication.
FrontPage 2003 system requirements. Installation Instruction: Download the installation file by clicking on the link below, save it to your computer. Baixar programa microsoft office frontpage 2003. Using HTML Tools is like having X-ray vision for your Web pages.
The routers have been pre-configured with the following passwords:. Enable password: ciscoenpa55. Password for vty lines: ciscovtypa55Note: Note: MD5 is the strongest encryption supported in the version of Packet Tracer used to develop this activity (v6.2). Although MD5 has known vulnerabilities, you should use the encryption that meets the security requirements of your organization. In this activity, the security requirement specifies MD5. Part 1: Configure OSPF MD5 Authentication Step 1: Test connectivity.
Cisco Packet Tracer 7.2 Crack
All devices should be able to ping all other IP addresses. Step 2: Configure OSPF MD5 authentication for all the routers in area 0.Configure OSPF MD5 authentication for all the routers in area 0.
R1(config)# router ospf 1R1(config-router)# area 0 authentication message-digest R2(config)# router ospf 1R2(config-router)# area 0 authentication message-digest R3(config)# router ospf 1R3(config-router)# area 0 authentication message-digest Step 3: Configure the MD5 key for all the routers in area 0.Configure an MD5 key on the serial interfaces on R1, R2 and R3. Use the password MD5pa55 for key 1.
R1(config)# interface s0/0/0R1(config-if)# ip ospf message-digest-key 1 md5 MD5pa55 R2(config)# interface s0/0/0R2(config-if)# ip ospf message-digest-key 1 md5 MD5pa55R2(config-if)# interface s0/0/1R2(config-if)# ip ospf message-digest-key 1 md5 MD5pa55 R3(config)# interface s0/0/1R3(config-if)# ip ospf message-digest-key 1 md5 MD5pa55 Step 4: Verify configurations.a. Verify the MD5 authentication configurations using the commands show ip ospf interface.b. Verify end-to-end connectivity. Part 2: Configure NTP Step 1: Enable NTP authentication on PC-A.a. On PC-A, click NTP under the Services tab to verify NTP service is enabled.b.
To configure NTP authentication, click Enable under Authentication. Use key 1 and password NTPpa55 for authentication. Step 2: Configure R1, R2, and R3 as NTP clients. R1(config)# ntp server 192.168.1.5R2(config)# ntp server 192.168.1.5R3(config)# ntp server 192.168.1.5Verify client configuration using the command show ntp status. Step 3: Configure routers to update hardware clock.Configure R1, R2, and R3 to periodically update the hardware clock with the time learned from NTP.
R1(config)# ntp update-calendarR2(config)# ntp update-calendarR3(config)# ntp update-calendarExit global configuration and verify that the hardware clock was updated using the command show clock. Step 4: Configure NTP authentication on the routers.Configure NTP authentication on R1, R2, and R3 using key 1 and password NTPpa55. R1(config)# ntp authenticateR1(config)# ntp trusted-key 1R1(config)# ntp authentication-key 1 md5 NTPpa55 R2(config)# ntp authenticateR2(config)# ntp trusted-key 1R2(config)# ntp authentication-key 1 md5 NTPpa55 R3(config)# ntp authenticateR3(config)# ntp trusted-key 1R3(config)# ntp authentication-key 1 md5 NTPpa55 Step 5: Configure routers to timestamp log messages.Configure timestamp service for logging on the routers.
R1(config)# service timestamps log datetime msecR2(config)# service timestamps log datetime msecR3(config)# service timestamps log datetime msec Part 3: Configure Routers to Log Messages to the Syslog Server Step 1: Configure the routers to identify the remote host (Syslog Server) that will receive logging messages. R1(config)# logging host 192.168.1.6R2(config)# logging host 192.168.1.6R3(config)# logging host 192.168.1.6The router console will display a message that logging has started. Step 2: Verify logging configuration.Use the command show logging to verify logging has been enabled. Step 3: Examine logs of the Syslog Server.From the Services tab of the Syslog Server’s dialogue box, select the Syslog services button. Observe the logging messages received from the routers.Note: Log messages can be generated on the server by executing commands on the router. For example, entering and exiting global configuration mode will generate an informational configuration message.
You may need to click a different service and then click Syslog again to refresh the message display. Part 4: Configure R3 to Support SSH Connections Step 1: Configure a domain name.Configure a domain name of ccnasecurity.com on R3. R3(config)# ip domain-name ccnasecurity.com Step 2: Configure users for login to the SSH server on R3.Create a user ID of SSHadmin with the highest possible privilege level and a secret password of ciscosshpa55. R3(config)# username SSHadmin privilege 15 secret ciscosshpa55 Step 3: Configure the incoming vty lines on R3.Use the local user accounts for mandatory login and validation. Accept only SSH connections.
R3(config)# line vty 0 4R3(config-line)# login localR3(config-line)# transport input ssh Step 4: Erase existing key pairs on R3.Any existing RSA key pairs should be erased on the router. R3(config)# crypto key zeroize rsaNote: If no keys exist, you might receive this message:% No Signature RSA Keys found in configuration. Step 5: Generate the RSA encryption key pair for R3.The router uses the RSA key pair for authentication and encryption of transmitted SSH data. Configure the RSA keys with a modulus of 1024. The default is 512, and the range is from 360 to 2048. R3(config)# crypto key generate rsaThe name for the keys will be: R3.ccnasecurity.comChoose the size of the key modulus in the range of 360 to 2048 for yourGeneral Purpose Keys. Choosing a key modulus greater than 512 may takea few minutes.How many bits in the modulus 512: 1024% Generating 1024 bit RSA keys, keys will be non-exportable.OKNote: The command to generate RSA encryption key pairs for R3 in Packet Tracer differs from those used in the lab.
Step 6: Verify the SSH configuration.Use the show ip ssh command to see the current settings. Verify that the authentication timeout and retries are at their default values of 120 and 3. Step 7: Configure SSH timeouts and authentication parameters.The default SSH timeouts and authentication parameters can be altered to be more restrictive. Set the timeout to 90 seconds, the number of authentication retries to 2, and the version to 2. R3(config)# ip ssh time-out 90R3(config)# ip ssh authentication-retries 2R3(config)# ip ssh version 2Issue the show ip ssh command again to confirm that the values have been changed. Step 8: Attempt to connect to R3 via Telnet from PC-C.Open the Desktop of PC-C. Select the Command Prompt icon.
Packet Tracer Activity Wizard Password
From PC-C, enter the command to connect to R3 via Telnet. PC telnet 192.168.3.1This connection should fail because R3 has been configured to accept only SSH connections on the virtual terminal lines. Step 9: Connect to R3 using SSH on PC-C.Open the Desktop of PC-C. Select the Command Prompt icon. From PC-C, enter the command to connect to R3 via SSH. When prompted for the password, enter the password configured for the administrator ciscosshpa55.
PC ssh –l SSHadmin 192.168.3.1 Step 10: Connect to R3 using SSH on R2.To troubleshoot and maintain R3, the administrator at the ISP must use SSH to access the router CLI. From the CLI of R2, enter the command to connect to R3 via SSH version 2 using the SSHadmin user account. When prompted for the password, enter the password configured for the administrator: ciscosshpa55. R2# ssh –v 2 –l SSHadmin 10.2.2.1 Step 11: Check results.Your completion percentage should be 100%.
Click Check Results to view the feedback and verification of which required components have been completed.
